ISM-3 grain winnower – grain cleaning and calibration

Grain cleaner ISM-3 Galvanized

2 500 €

ISM-3 grain winnower – grain cleaning and calibration. A compact, high-performance separator for producing top-quality seed. Effective separation without the use of sieves, guaranteeing grain purity of up to 98%.

Technical information

Productivity during primary grain cleaning

up to 3 tons per hour.

Productivity during calibration

up to 1.5 tons per hour.

Electricity consumption

0,2–0,55 kWh

Power supply

230 V

Appointment

Calibration, Primary cleaning

Number of fractions

Type

Non-cyclone

Length

1800mm

Width

550 mm

Heights

1800mm

Weight

110 kg

Warranty

24 months

Description

The ISM-3 aerodynamic separator is a state-of-the-art machine for cleaning and sorting grain.

The main feature that sets this model apart is its compact design, which allows for easy installation of the separator even in the limited space available on farms and in processing plants.

Advantages of the ISM aerodynamic separator:

▪︎ Compact dimensions:

Thanks to its well-designed construction, the ISM-3 separator takes up very little space, which is particularly important in facilities with limited space. Its mobility and ease of installation make it ideal for flexible use at various stages of production.

▪︎ Low energy consumption:

Energy efficiency is a key aspect of modern manufacturing. The ISM-3 separator offers high performance with minimal electricity consumption.

▪︎ High purification efficiency:

Precise control of the air flow and carefully selected operating parameters of the separator enable the removal of even the smallest impurities, which directly impacts the quality of the final product and increases its market value.

▪︎ Versatility:

The ISM-3 separator is used in various sectors of agriculture and the food industry, effectively handling different types of grain, seeds and other bulk materials.

▪︎ Ease of use and maintenance:

The simple control system makes it easy to configure the separator according to the type of grain, its contamination level and moisture content.

The ISM-3 grain separator is an essential piece of equipment in many industrial processes, including:

▪︎ Cleaning the grain before storage or further processing.

▪︎ Sorting seeds before sowing, which ensures a higher-quality crop.

▪︎ Removal of light contaminants during the production of feed and feed ingredients.

▪︎ Preparing raw materials for the production of flour, groats and other cereal products.
